862H－862H (Stage II)

Operating weight	20,400 kg	44,974 lbs
Standard bucket	4.0 m³	5.2 yd³
Rated power	179 kW (240 hp / 243 ps) @ 2,200 rpm	179 kW (240 hp / 243 ps) @ 2,200 rpm
Maximum gross power	179 kW (240 hp / 243 ps) @ 2,200 rpm	179 kW (240 hp / 243 ps) @ 2,200 rpm
Rated load capacity	6,500 kg	14,330 lbs
Hydraulic cycle time	9.3 s	9.3 s
Raise time	5.2 s	5.2 s
Maximum travel speed	35 km/h	21.7 mph
Tipping load-full turn	14,200 kg	31,306 lbs
Bucket breakout force	180 kN	40,466 lbf
Dump clearance, full height discharge	3,253 mm	10'8''
Dump reach, full height discharge	1,122 mm	3'8''
Model	Cummins 6LTAA8.9	Cummins 6LTAA8.9
Emissions	EPA Tier 2 / EU Stage II	EPA Tier 2 / EU Stage II
Aspiration	Turbocharged ﹠ air-to-air intercooled	Turbocharged ﹠ air-to-air intercooled
Length with bucket down	8,740 mm	28'8''
Width over tires	2,880 mm	9'5''
Cab height	3,500 mm	11'48''
Turning radius, outside of tire	6,650 mm	21.8 ft.
Bucket capacity	3.0-6.0 m³	3.9-7.8 yd³
General Purpose bucket	4.0 m³	5.2 yd³
Light material bucket	5.8, 7.2 m³	7.6, 9.4 yd³
Rock bucket	3.3, 4.0 m³	4.3, 5.2 yd³
Download Brochure

862H－862H (Stage IIIA)

Operating weight	20,636 kg	45,195 lbs
Standard bucket	4.0 m³	5.2 yd³
Rated power	180 kW (241 hp / 245 ps) @ 2,200 rpm	180 kW (241 hp / 245 ps) @ 2,200 rpm
Maximum gross power	190 kW (255 hp / 258 ps) @ 2,200 rpm	190 kW (255 hp / 258 ps) @ 2,200 rpm
Rated load capacity	6,500 kg	14,330 lbs
Hydraulic cycle time	9.3 s	9.3 s
Raise time	5.2 s	5.2 s
Maximum travel speed	38 km/h	23.6 mph
Tipping load-full turn	14,742 kg	32500.55 lbs
Bucket breakout force	178 kN	40,016 lbf
Dump clearance, full height discharge	3,253 mm	10'8''
Dump reach, full height discharge	1,122 mm	3'8''
Model	Cummins QSL9.3	Cummins QSL9.3
Emissions	EPA Tier 3 / EU Stage III	EPA Tier 3 / EU Stage III
Aspiration	Turbocharged ﹠ air-to-air intercooled	Turbocharged ﹠ air-to-air intercooled
Length with bucket down	8,847 mm	29 ft.
Width over tires	2,880 mm	9'5''
Cab height	3,500 mm	11'6''
Turning radius, outside of tire	6,687 mm	21.9 ft.
Bucket capacity	3.0-6.0 m³	3.9-7.8 yd³
General purpose bucket	4.5 m³	5.89 yd³
Light material bucket	5.8, 7.2 m³	7.6, 9.4 yd³
Rock bucket	3.3, 4.0 m³	4.3, 5.2 yd³
Download Brochure
